Description

STX 36 Supersport Shock Absorber KA 744

Part number

KA 744

Type Code

S36PR1C1L

Single tube
S

Single tube

Piston diameter
36

Piston diameter: 36 mm

type P
P

Monotube high pressure gas type of shock absorber with external “piggy back” reservoir.

R1 rebound damping adjuster
R1

Adjustable rebound damping on single tube shocks. Adjuster wheel above the end eye.

S36 C1 compression damping adjuster
C1

Adjustable compression damping. Adjuster wheel or slot on the reservoir.

L
L

Adjustable length.

Technical data

Length: 320mm +6-0 mm
Stroke: 66 mm
Rate N/mm: 105 N/mm
Position: rear
Mounted spring: 60293-36
Spring series: 60293-xx
Packaging unit: pieces

Notes

Optional heavy duty springs 60293-41 (115 N/mm) and 60293-44 (120 N/mm) available.

Fits for vehicles

Download

Fitment Table
